Coalescing Filters

Model: 2258294320

Residual Oil Aerosol at Outlet: ≤0.5 ppm under rated airflow

Filter Media: Multi-layer gradient borosilicate micro glass fiber composite with hydrophobic & oleophobic surface coating

Rated Airflow: 43 m³/min

Max Working Pressure: 16 bar / 232 PSIG

Max Continuous Operating Temperature: ≤80℃

Recommended Service Life: 4000–6000 working hours or 12 months, whichever comes first

Airflow Direction: Outside-to-inside

Key Product Features

Frontline Full System Barrier Protection

As the first defensive layer of compressed air purification system, it intercepts pipeline rust, scale, industrial dust, massive condensed condensate and bulky oil droplets. It drastically reduces pollutant load on downstream medium coalescing, ultra-precision and activated carbon filter elements, extends their service lifespan and prevents premature saturation of refrigerated dryer desiccant.

Low Pressure Drop Energy-saving Design

Optimized deep-pleated glass fiber media maximizes effective filtration area. It maintains stable low airflow resistance under 24-hour full-load continuous operation, cuts extra power consumption of air compressors and lowers overall factory air supply operation costs.

Extra Large Dirt & Liquid Holding Capacity

Multi-gradient layered depth filtration structure stores massive separated water, lubricating oil and solid contaminants, prolongs maintenance intervals and minimizes production downtime for filter replacement.

Impact-resistant Reinforced Plastic Support Cage

Inner and outer plastic frames withstand high-speed airflow impact, prevent filter media collapse, deformation and fiber shedding, eliminating secondary fiber contamination of clean compressed air under heavy-duty industrial conditions.

Working Principle

Raw unpurified compressed air flows into the cartridge from the outer plastic protective frame. The outer coarse fiber layer captures large solid particles, liquid water and bulky oil droplets; minor oil mist is pre-coalesced into heavy liquid droplets that sink to the housing bottom drain port and discharge automatically by gravity. Primarily purified compressed air flows into the secondary medium coalescing filter for further deep oil removal.

Application & Industries

Serves as the first-stage coarse protective filter in medium-large flow compressed air purification systems, installed upstream of medium coalescing filters and refrigerated air dryers.

Widely used in heavy machinery manufacturing, automotive production lines, packaging printing industrial parks, textile factories, general industrial spray painting, large pneumatic tool stations, food primary processing, medium & heavy-duty laser cutting and factory centralized compressed air supply systems.
