Model : 6.4566.1
Type : Air Filters
Replacement for : 6.4566.1
Height : 240 mm
It is made of high-density imported cellulose media with radial pleated structure, featuring large dust holding capacity and low airflow resistance. The anti-aging rubber end caps deliver tight sealing to prevent air leakage. It performs reliably under harsh working conditions and effectively protec
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
Part No: 6.4566.1
Product Name: Air Filter Element
Specifications
Filter Media: High-efficiency cellulose filter paper
Filtration Accuracy: 5–10 μm
Filtration Efficiency: ≥98%
Outer Diameter: 165 mm
Inner Diameter: 86 mm
Height: 240 mm
End Cap: Integrated anti-aging rubber seal, leak-proof
Operating Temperature: -10°C to +85°C
Service Life: 2000–2500 hours under normal conditions
Quality Standard: ISO 9001 certified
Function
It removes dust and solid impurities from intake air, reduces wear on core components, slows down lubricant contamination and maintains stable operating efficiency of the compressor.
Key Features
High filtration efficiency with low pressure drop for energy saving
Optimized pleat design for larger dust capacity and longer service intervals
Excellent sealing performance to avoid unfiltered air bypass
Vibration and moisture resistant, suitable for industrial and construction sites
