Air Filters

Model: 6.4198.0

Type: Heavy-duty cylindrical air filter

Construction  Materials

Media: High‑efficiency pleated cellulose filter paper

Outer/Inner Cage: Perforated galvanized steel for structural support and collapse resistance

End Caps: Rigid polyurethane  sealing gasket for leak‑tight installation

Shape: Tall cylindrical, deep‑pleated to maximize filtration area and dust holding capacity

Technical Specifications

Outer Diameter: 420 mm

Inner Diameter: 245 mm

Height: 388 mm

Weight: Approx. 5.76 kg

Filtration Efficiency: ≥98%

Particle Retention: 5–10 μm

Service Life: 2,000 hours

Pressure Drop: Low initial resistance to minimize energy consumption

Working Principle

As the compressor operates, it draws in large volumes of ambient air. The 6.4198.0 removes airborne contaminants through three key mechanisms:

Surface Interception: Large dust particles are trapped on the outer pleated surface.

Depth Filtration: Medium‑sized particles penetrate the porous paper and become embedded within the fiber layers.

Adsorption: Fine dust and moisture adhere to the cellulose fibers via electrostatic and van der Waals forces.

Only clean air passes through the center of the filter into the compressor’s airend, protecting rotors, bearings, and other precision components from abrasive wear. This ensures stable performance, reduces maintenance costs, and extends equipment service life.

Cross‑Reference / Equivalent Parts

High Dust Holding Capacity: Longer service intervals and reduced maintenance frequency

Low Pressure Drop: Saves energy by reducing compressor intake resistance

Rigid Construction: Metal cage prevents deformation under high airflow or vibration
