Model : 24091712
Type : Air Filters
Replacement for : 24091712
Height : 220 mm
It removes dust, sand, and other contaminants from intake air to safeguard the compressor’s main components. With premium filter media and robust structure, it performs reliably in harsh environments, ensuring stable and efficient compressor operation.
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
Model: 24091712
Type: Air Filter Element
Specifications
Outer Diameter: 280 mm
Inner Diameter: 180 mm
Height: 220 mm
Filter Media: High‑efficiency cellulose / glass fiber composite
Filtration Precision: 5–10 μm
Filtration Efficiency: ≥99.5%
Service Life: 2000–4000 hours
Initial Pressure Drop: ≤0.02 MPa
Working Temperature: 0°C to 100°C
Weight: ~1.2 kg
Structure: Pleated media, metal end caps, rubber seal
Features
High‑Efficiency Media: 99.5%+ efficiency at 5–10 μm, protects rotors and bearings.
Low Pressure Drop: Optimized pleat design reduces energy consumption.
Durable Construction: Metal end caps and rubber seal resist vibration and prevent air leakage.
Long Service Life: High dirt‑holding capacity extends maintenance intervals.
Description
It removes dust, sand, and other contaminants from intake air to safeguard the compressor’s main components. With premium filter media and robust structure, it performs reliably in harsh environments, ensuring stable and efficient compressor operation.
