Model : 2117909
Type : Air Filters
Replacement for : 2117909
Height : 254 mm
It adopts high-density pleated filter media with oil-resistant rubber end caps. This filter shares the same structure and dimensions as SA6856, perfectly suitable for small and medium screw compressors, construction machinery and generator sets. It delivers stable filtration performance and long ser
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
Part No: 2117909
Product Name: Air Filter Element
Specifications
Filter Media: High-efficiency pleated cellulose
Filtration Accuracy: 5 μm
Filtration Efficiency: ≥99.5%
Outer Diameter: 152 mm
Inner Diameter: 92 mm
Height: 254 mm
Structure: Oil-resistant rubber end caps
Operating Temperature: -10°C to +80°C
Service Life: 2000–3000 hours under normal conditions
Function
It removes dust, sand and solid contaminants from intake air. Effectively protects compressor rotors, bearings and engine cylinders from abrasion, keeps equipment operating stably, reduces energy consumption and extends service life.
Key Features
Low pressure drop design to save energy and maintain equipment output
Fully sealed rubber end caps, anti-vibration and air leakage proof
Reinforced filter paper with support mesh, good deformation resistance and large dust holding capacity
