Model : 1625769200
Type : Air Filters
Replacement for : 1625769200
Height : 210 mm
It removes solid contaminants, carbon deposits, and metal wear particles from lubricating oil, protecting rotors, bearings, and gears. Designed for high pressure and continuous operation, it ensures clean oil, stable performance, and extended compressor life.
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
Model: 1625769200
Type: Oil Filter Element
Specifications
Outer Diameter: 98 mm
Height: 210 mm
Weight: 0.95 kg
Media: High‑efficiency glass fiber / cellulose
Filtration Precision: 10–15 μm
Filtration Efficiency: ≥98.8%
Service Life: 2000–3000 hours
Initial Pressure Drop: ≤0.02 MPa
Max Working Pressure: 1.4–2.5 MPa
Features
Spin‑on Design: Easy, tool‑free replacement; no housing disassembly needed.
High‑Efficiency Media: Captures fine metal particles, carbon deposits, and sludge.
Heavy‑Duty Construction: Steel casing with anti‑corrosion coating; burst‑resistant.
Description
It removes solid contaminants, carbon deposits, and metal wear particles from lubricating oil, protecting rotors, bearings, and gears. Designed for high pressure and continuous operation, it ensures clean oil, stable performance, and extended compressor life.
