Air Filters

Main Content:​

The assembly consists of high-efficiency filtration media , a metal internal support screen/frame, and polyurethane sealing end caps.

Key Features:​

Cylindrical cartridge design providing a large filtration area with low pressure drop. High filtration efficiency  at a rating of approximately 5–10 microns. Effectively traps dust, sand, pollen, soot, and airborne contaminants. High dust-holding capacity and robust pleat stability. Designed for a service life of approximately 2000 hours.

Primary Use / Application:​

Used as an intake air filter element in industrial screw air compressors . It is installed at the air inlet to filter ambient air drawn into the compressor, preventing abrasive particles from entering the compression chamber, thereby protecting rotors, oil filters, and separators.

Dimensions / Size:​

Outer Diameter:​ 135 mm

Inner Diameter:​ 85 mm

Height:​  305 mm
