The 007.0171-0 is a heavy-duty spin-on oil filter, widely used in screw air compressors, industrial diesel engines and heavy machinery lubrication systems. It effectively removes metal particles, carbon deposits, sludge and fine contaminants from lubricating oil, maintains oil circuit cleanliness, reduces component friction and wear, and ensures stable equipment operation under high-load and high-temperature conditions.

Key Features

High-efficiency composite filter media with stable 10 μm filtration accuracy and large dirt-holding capacity for extended service intervals.

Built-in anti-drain back valve prevents oil backflow after shutdown and protects equipment from dry-start damage.

Internal bypass valve guarantees continuous oil supply during cold start or when the filter becomes clogged.

Reinforced thick steel shell with high pressure resistance, suitable for harsh industrial working environments.

Premium nitrile rubber sealing ring provides excellent heat and aging resistance, ensuring tight fit and reliable leak prevention.

Standard thread and overall dimensions enable easy installation and direct replacement without modification.

Technical Specifications

Part Number: 007.0171-0

Type: Spin-on Oil Filter

Outer Diameter: 96 mm

Overall Height: 142 mm

Seal Outer Diameter: 72 mm

Seal Inner Diameter: 61 mm

Application

Suitable for screw air compressors, industrial generators, construction machinery and other industrial equipment with matching installation standards.
