Oil Separators Filters

Part No:DB2132

Product Type: Screw air compressor internal tank‑mounted air‑oil separator element

Filter Media: Borosilicate glass‑fiber coalescing composite media

Residual oil content: ≤2‑3 ppm

Max Working Pressure:16 bar

Operating Temperature:‑20℃ ~ +85℃

Dimension: OD200 mm, ID108 mm, Height 305 mm, Net weight 2.52 kg

Recommended Service Life:4000‑6000 working hours. Replace immediately for high pressure‑drop or oil carry‑over. Cannot be cleaned, must be replaced directly.

Main Features

High‑efficiency glass‑fiber coalescing media captures oil mist from compressed‑air, separated oil drains back to separator tank.

Filter media resists compressor oil and moisture, withstands system pressure fluctuations.

Matching oil‑resistant flange gasket prevents oil‑gas bypass and oil carry‑over.

Core consumable of compressor three‑filter set, determines residual oil content of compressed‑air.

Application Industries

Screw compressor systems, general manufacturing, spray painting and rubber‑plastic industries. Provides low‑oil clean compressed‑air for oil‑injected screw compressors.

Product Summary

DB2132 is internal tank‑mounted air‑oil separator element. Coalescing glass‑fiber media separates oil mist and returns separated oil, delivering clean compressed‑air for industrial processes
