Model : 57258114
Type : Oil Separators Filters
Replacement for : 57258114
57258114 is internal tank‑mounted air‑oil separator element. Coalescing glass‑fiber media separates oil mist and returns separated oil, delivering clean compressed‑air for industrial processes.
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
Part No:57258114
Product Type: Screw air compressor internal tank‑mounted air‑oil separator element
Filter Media: Borosilicate glass‑fiber coalescing composite media
Residual oil content: ≤2‑3 ppm
Max Working Pressure:16 bar
Operating Temperature:‑20℃ ~ +85℃
Construction: Flange plate, glass‑fiber media, inner support frame, sealing gasket, installed inside air‑oil separator tank
Compatible Models: Oil‑injected screw air compressors
Recommended Service Life:4000‑8000 working hours. Replace immediately for high pressure‑drop or oil carry‑over. Cannot be cleaned, must be replaced directly.
Main Features
High‑efficiency glass‑fiber coalescing media captures oil mist from compressed‑air, separated oil drains back to separator tank.
Filter media resists compressor oil and moisture, withstands system pressure fluctuations.
Matching flange sealing gasket prevents oil‑gas bypass and oil carry‑over.
Application Industries
Screw compressor systems, general manufacturing, spray painting and rubber‑plastic industries. Provides low‑oil clean compressed‑air for oil‑injected screw compressors.
Product Summary
57258114 is internal tank‑mounted air‑oil separator element. Coalescing glass‑fiber media separates oil mist and returns separated oil, delivering clean compressed‑air for industrial processes.
